Reperfusion therapy for acute ischaemic stroke

Intravenous thrombolysis therapy and ongoing clinical trials aimed at expanding the time frame for this particular therapy are reviewed in this article

Dr Karl Boyle, Clinical Stroke Fellow, St James's Hospital, Dublin

May 1, 2012

Article
Similar articles
  • Approved therapies for acute stroke include intravenous (IV) thrombolysis therapy with alteplase (recombinant tissue plasminogen activator [rtPA]) given within 4.5 hours, aspirin therapy within 48 hours; management in an acute stroke unit and hemicraniectomy in cases of malignant infarction.

    This article reviews the evidence for intravenous thrombolysis therapy, ongoing clinical trials aimed at expanding the narrow time window for thrombolysis therapy and clinical trials trying to identify subpopulations of stroke patients who may benefit from endovascular intervention.

    Intravenous thrombolysis

    Intravenous alteplase is the only thrombolytic agent with a European or American licence for the treatment of acute ischaemic stroke (AIS). Alteplase is a thrombolytic glycoprotein, produced by recombinant DNA techniques, which is administered by IV infusion.1 The National Institute of Neurological Disorders and Stroke (NINDS) trial was a landmark prospective, randomised, double-blind, placebo-controlled, multi-centre trial published in 1995 that established the efficacy of alteplase in AIS.2

    This study demonstrated that patients treated with alteplase within three hours of ischaemic stroke onset were at least 30% more likely to have minimal or no disability at three months compared to patients treated with placebo.

    However, patients treated with alteplase had an increased risk of symptomatic haemorrhage (ICH); there was no significant difference in mortality between the two groups. Alteplase therapy for treatment of AIS was recommended by the Food and Drug Administration (FDA) in 1995 and by the European Medicines Agency (EMA) in 2002.

    ECASS III was the next landmark thrombolytic trial that demonstrated alteplase remains safe and effective when administered to AIS patients within an extended 3-4.5 hour time window after stroke onset. ECASS III was a prospective, randomised, double-blind, parallel-group, multi-centre, international trial published in 2008.3

    This trial demonstrated that patients treated with alteplase were significantly more likely to have a favourable outcome (mRS score of 0 or 1) than those treated with placebo (52.4% versus 45.4%, OR 1.34, 95% C/I 1.02-1.76). Once again the rate of symptomatic ICH was significantly greater in patients treated with alteplase (2.4% versus 0.4%, p = 0.008).

    However, this was similar to the rates observed in other thrombolysis trials of patients treated with alteplase within three hours, including the NINDS trial. There was no difference in all-cause mortality between the two groups.

    Following publication of this trial several worldwide guidelines, including AHA/ESO/CSS, recommended use of rtPA for AIS up to 4.5 hours from symptom onset, although not licensed.4,5,6 A pooled analysis of all randomised controlled trials of alteplase in AIS confirmed benefit from IV alteplase therapy when treated up to 4.5 hours.7

    Data from large-scale patient registries (SITS-ISTR) have confirmed that these RCT results can be extended into clinical practice providing ample evidence of the efficacy and effectiveness of alteplase therapy given within 4.5 hours of symptom onset.8 To maximise benefit every effort should be made to shorten delay to treatment initiation.

    On November 4, 2011, alteplase gained approval for use in acute stroke up to 4.5 hours in 15 European countries, including Ireland, through a mutual recognition procedure.

    The problem with intravenous thrombolysis

    Published rates for patients actually receiving acute thrombolytic therapy are very low in the US and in Europe (1-3%).9,10 Despite earnest attempts to increase the use of IV thrombolysis, overall usage remains very low, even with the expansion of the time window for treatment up to 4.5 hours.

    Common reasons for exclusion include minor symptoms, rapidly resolving signs and uncertain time of stroke onset. For example, patients who go to sleep healthy and wake up with symptoms beyond the recommended time window (wake-up stroke) are not eligible for treatment based on current restrictions.

    A recent population-based study identified 273 (14.3%) of 1,854 ischaemic strokes presenting to an emergency department as wake-up strokes.11 It has been estimated that up to 18% of patients do not receive IV tPA when they are in fact eligible.12

    Development of national stroke strategies and public awareness campaigns have helped increase the number of AIS patients treated with IV thrombolysis in the UK. The National Sentinel Stroke Audit data in 2008 showed only 1% of all stroke patients received thrombolysis.13

    This figure has increased to 8% in the most recent Stroke Improvement National Audit Programme (SINAP) comprehensive report published in 2012.14 Reorganisation and centralisation of acute stroke services have also resulted in boosting the proportion of rtPA-treated patients. In 2006, 34 hospitals in London received blue light ambulances carrying patients who had suffered an acute stroke. London has now reorganised the earliest phase of acute stroke care around eight ‘stroke hubs’ called hyperacute stroke units (HASUs). Thrombolysis rates in London have increased from 3.5% in Feb-June 2009 to 14% in Feb-June 2010.15

    Despite these measures a large proportion of acute stroke patients do not receive thrombolytic therapy and clinical trials are underway attempting to expand the therapeutic time window.

    Extending window of time for intravenous alteplase therapy

    Two European trials, the European Cooperative Acute Stroke Study (ECASS) and ECASS II, investigated use of IV rtPA in a time window of up to six hours but failed to show the efficacy of thrombolytic therapy, as defined by each trial.16,17 IST-3 is an international, multi-centre, prospective, randomised, open, blinded end point (PROBE) trial of intravenous rtPA in AIS.18

    Inclusion criteria were straightforward – patients were required to have baseline imaging to exclude haemorrhage or stroke mimics and treatment should be started within six hours.

    There is much excitement among the stroke community as we may soon have evidence for benefit of intravenous thrombolysis in an older age group (patients > 80 years were not included in previous thrombolysis trials) and in an extended time window (0-6 hours). The results were due to be presented at the European Stroke Conference in Lisbon in May 2012.

    Extending window of time with alternative thrombolytic agents

    Currently, alteplase is the only thrombolytic agent licensed for treatment of AIS. Desmoteplase is a novel, highly fibrin-specific recombinant tissue plasminogen activator that occurs naturally in the vampire bat (Desmondus rotundus).

    Its use for the treatment of AIS in an extended time window (three to nine hours) is currently under evaluation. Although initial trials (DIAS and DEDAS) demonstrated safety and a high recanalisation rate, as identified by MRA, DIAS 2 failed to show any clinical benefit over placebo, despite a low rate of symptomatic haemorrhage.19,20,21

    These trials used identification of at least a 20% MRI perfusion-diffusion (or CT perfusion) mismatch as inclusion criterion. It is now felt that these early trial designs had forged too far ahead of imaging science as many technical parameters of perfusion-diffusion mismatch have yet to be established. Desmoteplase is currently being evaluated in a phase III clinical trial, DIAS 3/4 (depending on country site), to assess efficacy and safety in an extended time window (three to nine hours).22

    Interestingly the trial design now uses identification of a large vessel occlusion with non-invasive vessel imaging (MRA/CTA) as an entry criterion, rather than any identified perfusion-diffusion mismatch, although this parameter will still be evaluated in a predefined imaging subgroup analysis.

    More recently, tenecteplase (TNK), a genetically engineered mutant tissue plasminogen activator, has been evaluated for use as a thrombolytic agent in AIS. A phase IIB trial randomly assigned 75 patients to either alteplase or tenecteplase within six hours after the onset of ischaemic stroke.23

    Eligibility criteria included a perfusion lesion of at least 20% greater than infarct core on CT perfusion imaging at baseline and an associated vessel occlusion on CT angiography. TNK was associated with significantly better reperfusion and clinical outcomes than alteplase, representing a promising area for further research.

    The mismatch concept and extended time window

    Strictly time-based thrombolysis may not be the optimal treatment for any individual patient and there has been much research trying to substitute the time clock with attempts to identify the ischaemic penumbra as this is felt to more accurately reflect the underlying pathophysiology.

    Strategies evoke the mismatch concept to identify tissue at risk. Both MRI (perfusion-diffusion) and CT perfusion (mean transit time-cerebral blood volume) have been used to identify the ischaemic penumbra. EPITHET24 (alteplase, three to six hours), DIAS,19 DEDAS20 and DIAS 221 (desmoteplase, three to nine hours) were all randomised clinical trials using MRI or CT perfusion to identify ischaemic penumbra and guide thrombolysis decisions.

    Although clinical end points were negative a meta-analysis (also including the open-label multi-centre prospective trial DEFUSE) showed favourable outcome was more frequent with reperfusion and there was a higher degree of reperfusion after thrombolysis in those patients with a mismatch profile, thus establishing a ‘proof of principle’.

    However, problems persist including the absence of a gold standard for the mismatch definition, which imparts on treatment effect. Further larger RCTs are needed for further evaluation of MRI-based thrombolysis as a means to identify tissue at risk rather than an arbitrary time window.

    Extending the Time for Thrombolysis in Emergency Neurological Deficits (EXTEND) is an ongoing clinical trial using MRI perfusion-diffusion mismatch to identify patients suitable for IV rtPA within a nine-hour time window.25 MRI mismatch will be identified using an automated, standardised software solution.

    ECASS 4 is a proposed European multi-centre trial that will adopt the EXTEND protocol.26 WAKE-UP is an upcoming European, randomised, placebo-controlled clinical trial that will use MRI diffusion-FLAIR mismatch (as a surrogate to identify patients < 4.5 hours from stroke symptom onset) to prove the efficacy and safety of MRI-based thrombolysis in patients with unknown time of symptom onset.27

    The optimal role of multimodal imaging in acute stroke has not yet been established. The European Stroke Organisation (ESO) 2008 guidelines state: “The use of multimodal imaging criteria may be useful for patient selection (class III, level C)... Available data on mismatch, as defined by multimodal MRI or CT, are too limited to guide thrombolysis in routine practice.”28

    Intra-arterial thrombolysis

    Recanalisation of occluded arteries leading to reperfusion results in better outcomes. Studies have shown that the success rates for achieving vessel recanalisation vary with occlusion location, with more proximal occlusions in the distal internal carotid artery (ICA) and the proximal segment (M1) of the middle cerebral artery (MCA) being more resistant to thrombolytics in comparison to occlusions at more distal MCA divisions and cortical branches.29,30,31 Alternatives to IV tPA that can achieve reperfusion of large vessels are desperately needed.

    PROACT 1 and II are the only randomised studies that have examined the safety and efficacy of IA thrombolysis in patients with AIS.32,33 In the PROACT II study, prourokinase was given only proximal to the clot and mechanical clot disruption with the guide-wire was not allowed. Recanalisation was reported in 66% of the treatment group, with 40% favourable neurological outcome (mRS ≤ 2) and 25% 90-day mortality. These figures remain the standard for new devices and technologies a decade later.

    Mechanical clot retrieval

    See Figures 1(i)-3(ii) for images of a successful endovascular therapy case.

    Figure 1 (i): this and Figure 1(ii) show axial and coronal CT angiogram identifying proximal right MCA (M1) occlusion
    Figure 1 (i): this and Figure 1(ii) show axial and coronal CT angiogram identifying proximal right MCA (M1) occlusion(click to enlarge)

    Figure 1(ii): this and Figure 1 (i) show axial and coronal CT angiogram identifying proximal right MCA (M1) occlusion
    Figure 1(ii): this and Figure 1 (i) show axial and coronal CT angiogram identifying proximal right MCA (M1) occlusion(click to enlarge)

    Figure 2(i): CT perfusion imaging demonstrating large mismatch in the right MCA territory: CT source image
    Figure 2(i): CT perfusion imaging demonstrating large mismatch in the right MCA territory: CT source image(click to enlarge)

    Figure 2(ii): CT perfusion imaging demonstrating large mismatch in the right MCA territory: decreased blood flow
    Figure 2(ii): CT perfusion imaging demonstrating large mismatch in the right MCA territory: decreased blood flow(click to enlarge)

    Figure 2(iii): CT perfusion imaging demonstrating large mismatch in the right MCA territory: increased mean transit time
    Figure 2(iii): CT perfusion imaging demonstrating large mismatch in the right MCA territory: increased mean transit time(click to enlarge)

    Figure 2(iv): CT perfusion imaging demonstrating large mismatch in the right MCA territory: preserved blood volume
    Figure 2(iv): CT perfusion imaging demonstrating large mismatch in the right MCA territory: preserved blood volume(click to enlarge)

    Figure 3 (i): Cerebral angiogram before recanalisation with the Penumbra device
    Figure 3 (i): Cerebral angiogram before recanalisation with the Penumbra device(click to enlarge)

    Figure 3 (ii): Cerebral angiogram after successful recanalisation with the Penumbra device
    Figure 3 (ii): Cerebral angiogram after successful recanalisation with the Penumbra device(click to enlarge)

    Several devices aiming to aspirate or retrieve the occluding clot have been devised including the MERCI and Penumbra devices. Initial trials (Multi MERCI34 and Penumbra Pivotal Stroke Trial35), recruiting patients up to eight hours who are ineligible for or after failing IV thrombolysis therapy, were single-arm studies using historical controls for comparison. Results demonstrated good recanalisation rates (68% and 82%, respectively), but were less convincing for good clinical outcomes (36% and 25%). Ninety-day mortality rates were high (34% and 33%).

    Mechanical Retrieval and Recanalization of Stroke Clots Using Embolectomy (MR RESCUE) is an ongoing clinical study to compare the effectiveness of treating AIS with mechanical embolectomy using the MERCI or Penumbra device within eight hours of symptom onset, compared to standard medical treatment.36 A large vessel occlusion on MRA or CTA must be identified to meet entry criteria. Results are expected later this year.

    The most recent generation of mechanical device is the stent retriever (Solitaire, Trevo). The Solitaire With the Intention for Thrombectomy (SWIFT) trial was a US multi-centre RCT with blinded end point comparing the Solitaire and MERCI devices in a head-to-head trial.37 Patients were treated within eight hours if ineligible for, or they had failed, IV rtPA. The trial was stopped almost a year early because of significantly better outcomes with the new Solitaire device.

    Solitaire is also undergoing evaluation in the international single-arm STAR trial (Solitaire FR Thrombectomy for Acute Revascularization), aiming to recruit 200 consecutive patients with anterior circulation occlusion treated within a window of eight hours.38 First results are expected mid-2012.

    The Trevo device is undergoing further evaluation in the Thrombectomy Revascularization of Large Vessel Occlusion in Acute Ischemic Stroke (TREVO) trial in the US and Europe.39

    Bridging therapy

    The International Management of Stroke III trial (IMS-III) is a phase III, randomised, open-label trial aiming to enrol 900 patients with a NIHSS of eight or more within three hours.40 The aim of the study was to examine whether the combined IV and IA approach was superior to standard IV rtPA alone. In recent weeks NINDS has stopped enrolment, on the recommendations of the DSMB.

    This is because the data collected to date show no difference in clinical outcome for those patients treated with IV rtPA alone, versus those treated with IV rtPA plus an FDA-cleared intra-arterial therapy (including the MERCI, Penumbra and, more recently, Solitaire devices). There were no safety concerns.

    With the suspension of IMS-III, another bridging trial, the Randomized, Concurrent Controlled Trial to Assess the Penumbra System’s Safety and Effectiveness in the treatment of Acute Stroke (THERAPY), will take on more significance.41 This trial has the additional criterion of identification of a large clot burden (clot length > 8mm) in the anterior circulation and will compare IV rtPA alone versus combined IV rtPA with the Penumbra device.

    Summary

    The management of acute ischaemic stroke is rapidly evolving. IV thrombolysis therapy has an established evidence base for efficacy and safety when given within 4.5 hours of stroke onset. However, not all patients meet criteria for rtPA and over half of those treated with IV rtPA remain disabled so the search will continue for new and improved therapies.

    Many studies are attempting to expand the therapeutic time window, using both alteplase and other novel thrombolytic agents, and/or advanced neuroimaging to identify the ischaemic penumbra and potentially salvageable brain tissue beyond 4.5 hours.

    However, many unanswered questions remain about the role of advanced neuroimaging in hyperacute stroke treatment. Certainly identification of large vessel occlusion with MRA or CTA and identification of mismatch using CT or MRI perfusion imaging appear promising for patient selection to new therapies, but their role remains undefined and is the subject of ongoing research.

    The place of endovascular intervention is also not yet known. Patient selection will be key, but which patient subgroups will benefit? Stroke severity (eg. NIHSS > 10), vessel occlusion site (ICA, MCA, BA), clot burden, eg. > 8mm, mismatch identified with MRI or CT perfusion imaging and collateral circulation status are all important variables that are the subject of ongoing research.

    IV rtPA therapy for AIS has been established in several RCTs looking at clinical outcomes versus placebo, whereas embolectomy has evidence only from single-arm studies due to different regulatory approval criteria for drugs versus devices. Unfortunately, much of the interventional stroke treatment currently taking place is outside of clinical trials without the collection of much-needed data.

    Much work is taking place on a national level to improve public awareness of stroke symptoms and to develop stroke services. In the future, all stroke patients should be directly admitted to a stroke unit equipped to manage acute stroke patients. All stroke patients should have access to a stroke service that can deliver intravenous thrombolysis therapy safely and effectively 24/7 and all patients who are eligible for thrombolysis should receive it. Telemedicine will become available to help local hospitals cope with the complexity of acute stroke treatment.

    References

    1. Actilyse. Summary of Product Characteristics, October 2002. Boehringer Ingelheim.
    2. National Institute of Neurological Disorders and Stroke rt-PA Stroke Study Group. Tissue plasminogen activator for acute ischemic stroke. NEJM 1995;333:1581-7
    3. Hacke et al. Thrombolysis with alteplase 3 to 4.5 hours after acute ischemic stroke. NEJM 2008;359:1317-29
    4. Del Zoppo et al. Expansion of the time window for treatment of acute ischaemic stroke with intravenous tissue plasminogen activator: a science advisory from he AHA/ASA. Stroke 2009;40:2945-8
    5. European Stroke Organization (ESO) Guidelines for Management of Ischaemic Stroke - update 2009. www.eso-stroke.org/recommendations.php
    6. Canadian Stroke Strategy (CSS) Canadian Best Practice Recommendations for acute stroke care - update 2010. www.strokebestpractices.ca/index/php/hyperacute-stroke-management
    7. Lees et al. Time to treatment with intravenous alteplase and outcome in stroke: an updated pooled analysis of ECASS, ATLANTIS, NINDS and EPITHET trials. Lancet 2010;375:1695-703
    8. Wahlgren et al. Thrombolysis with alteplase 3-4.5h after acute ischaemic stroke (SITS-ISTR): an observational study. Lancet 2008;372:1303-09
    9. Majersik et al. Population-based analysis of the impact of expanding the time window for acute stroke treatment. Stroke 2007;38:3213-3217
    10. Schumacher et al. Use of thrombolysis in acute ischemic stroke: analysis of the nationwide inpatient sample 1999 to 2004. Ann Emerg Med 2007;50:99-107
    11.  Mackey et al. Population-based analysis of wake-up strokes. Neurology 2011;76:1662-1667
    12. Cocho et al. Reasons for exclusion from thrombolytic therapy following acute ischemic stroke. Neurology 2005;64:719-20
    13. http://www.rcplondon.ac.uk/resources/national-sentinel-stroke-audit
    14. http://www.rcplondon.ac.uk/resources/stroke-improvement-national-audit-programme-sinap
    15. http://www.london.nhs.uk/news-and-health-issues/press-releases/latest-press-releases/stroke-victims-in-london-have-better-access-to-life-saving-treatment-than-anywhere-else-in-the-world
    16. Hacke et al. Intravenous thrombolysis with recombinant tissue plasminogen activator for acute hemispheric stroke: the European Cooperative Acute Stroke Study (ECASS). JAMA 1995;274:1017-25
    17. Hacke et al. Randomized double-blind placebo-controlled trial of thrombolytic therapy with intravenous alteplase in acute ischaemic stroke (ECASS II). Lancet 1998;352:1245-51
    18. http://www.strokecenter.org/trials/clinicalstudies/third-international-stroke-trial
    19. Hacke et al. The Desmoteplase in Acute Ischemic Stroke trial (DIAS). A phase II MRI-based 9-hour window acute stroke thrombolysis trial with intravenous desmoteplase. Stroke 2005;36:66-73
    20. Furlan et al. Dose Escalation of Desmoteplase for Acute Ischemic Stroke (DEDAS): evidence of safety and efficacy 3 to 9 hours after stroke onset. Stroke 2006;37:1227-31
    21. Hacke et al. Intravenous desmoteplase in patients with acute ischemic stroke selected by MRI perfusion-diffusion weighted imaging or reperfusion CT (DIAS-2): a prospective, randomised, double blind, placebo-controlled study. Lancet Neuro 2009;8:141-50
    22.  http://clinicaltrials.gov/ct2/show/NCT00790920 (DIAS 3/4)
    23. Parsons et al. A Randomized Trial of Tenecteplase versus Alteplase for Acute Ischemic Stroke. NEJM 2012;366:1099-1107
    24. Davies et al. Effects of alteplase beyond 3 h after stroke in the Echoplanar Imaging Thrombolytic Trial (EPITHET): a placebo controlled randomised trial. Lancet Neurol 2008;7:299-309
    25. http://clinicaltrials.gov/ct2/show/NCT00887328 (EXTEND)
    26. ECASS 4 - information received from Peter Ringleb
    27. http://clinicaltrials.gov/ct2/show/NCT01525290 (WAKE-UP)
    28. Guidelines for the management of Ischaemic Stroke and Transient Ischaemic Attack 2008. European Stroke Organization (ESO) Executive Committee and the ESO Writing Committee. Cerebrovasc Dis 2008;25:457-507
    29. Christou et al. Intravenous tissue plasminogen activator and flow improvement in acute ischemic stroke patients with internal carotid occlusion. J Neuroimaging 2002;12:119-23
    30. del Zoppo et al. recombinant tissue plasminogen activator in acute thrombotic and embolic stroke. Ann Neurol 1992;32:78-86
    31. Molina et al. Improving the predictive accuracy of recanalization on stroke outcome in patients with tissue plasminogen activator. Stroke 2004;35:151-6
    32. del Zoppo et al. PROACT: A phase 11 randomized trial of recombinant pro-urokinase by direct arterial delivery in acute middle cerebral artery stroke. Stroke 1998;29:4-11
    33. Furlan et al. Intra-arterial prourokinase for acute ischemic stroke. The PROACT II study: a randomized controlled trial. Prolyse in Acute Cerebral Thromboembolism. JAMA 1999;282:2003-2011
    34. Smith et al. Mechanical thrombectomy for acute ischemic stroke: final results of the Multi MERCI trial. Stroke 2008;39:1205-1212
    35. The penumbra pivotal stroke trial: safety and effectiveness of a new generation of mechanical device for clot removal in intracranial large vessel occlusive disease. Stroke 2009;40:2761-2768
    36. http://clinicaltrials.gov/ct2/show/NCT00389467 (MR RESCUE)
    37. SWIFT results presented by Jeffrey Saver at the International Stroke Conference Feb 2012 New Orleans.
    38. http://clinicaltrials.gov/ct2.show/NCT01327989 (STAR)
    39. http://clinicaltrials.gov/ct2/show/NCT01088672 (TREVO)
    40. http://clinicaltrials.gov/ct2/show/NCT0035942 (IMS III)
    41. http://clinicaltrials.gov/ct2/show/NCT01429350 (THERAPY)
